Arcade Machine Cores

The MEGA65 can also be turned into an arcade game machine. As many early arcade games rely on fast reaction times, an FPGA-based recreation is much more faithful than software emulation. Unfortunately, arcade games usually require a complete FPGA slot for a single game.

Important Details about Arcade Games

To recreate the game two parts are needed: An FPGA Core and image files for the ROMs. The Core is like a Core for a home computer and only has the “hardware” part of the machine. It still requires the actual software, which is a seperate file, even if the Core can only play one specific game. Arcade Game ROMs are available in many flavours on internet, but the Core usually requires a very specific format. You need to read the instructions per Core very carefully and follow them to the letter to create the correct files. This in some cases requires Python on your computer. Due to copyright and licensing reasons, there is no official archive where Cores and ROMs are bundled ready to use.

Some Arcade Machine Cores support “DIP Switches”. This refers to the switches on the arcade board itself and these are shown on screen. Do not open the MEGA65 to change the DIP switches inside.

GameLinkComments
1942Github
1943Github
Bank PanicGithub
Black TigerGithub
BosconianGithub
Bomb JackGithub
Bump’n’JumpGithubalso known as “Burnin’ Rubber”
CommandoGithub
Dig DugGithub
Double DragonGithub
Elevator ActionGithub
Exed ExesGithub
GalagaGithub
GaplusGithub
GalaxianGithub
Ghosts’n GoblinsGithubR3 only, ported to R6 here
GunsmokeGithub
GyrussGithub
Mr. Do!Github
Pac-LandGithub
Psycho-Nics OscarGithub
Rush’n AttackGithubalso known as “Green Beret”
Sega System 1GithubChoplifter, Pitfall II, Up’n’down, Wonderboy, Wonderboy in Monsterland
Space InvadersFilehost
StargateGithub
XeviousGithubR3 only, ported to R6 here
Yie Ar Kung-FuGithub
